R20515RS02Q

Image is for reference, please contact us to get the real picture

Manufacturer Part
R20515RS02Q
Manufacturer
C&K
Description
SWITCH ROTARY 5POS 5A 125V
Category
Switches
Family
Rotary Switches
Series
-
In Stock
0
Datasheets
-

R20515RS02Q Specifications

  • Series:R
  • Package:Tray
  • Part Status:Active
  • Number of Positions:5
  • Index Stops:Fixed
  • Number of Decks:1
  • Number of Poles per Deck:2
  • Circuit per Deck:DP5T
  • Contact Timing:Non-Shorting (BBM)
  • Current Rating (Amps):5A (AC), 500mA (DC)
  • Voltage Rating - AC:125 V
  • Voltage Rating - DC:125 V
  • Actuator Type:Screwdriver Slot
  • Actuator Length:Flush
  • Angle of Throw:36°
  • Contact Material:Copper
  • Contact Finish:Silver
  • Mounting Type:Through Hole
  • Termination Style:PC Pin
  • Features:-
  • Depth Behind Panel:10.29mm
