AOTF260L Specifications

• Series:-
• Package:Tube
• Part Status:Not For New Designs
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):60 V
• Current - Continuous Drain (Id) @ 25°C:19A (Ta), 92A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):6V, 10V
• Rds On (Max) @ Id, Vgs:2.6mOhm @ 20A, 10V
• Vgs(th) (Max) @ Id:3.2V @ 250µA
• Gate Charge (Qg) (Max) @ Vgs:210 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:11800 pF @ 30 V
• FET Feature:-
• Power Dissipation (Max):1.9W (Ta), 46.5W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Through Hole
• Supplier Device Package:TO-220-3F
• Package / Case:TO-220-3 Full Pack
