AOW284 Specifications

• Series:AlphaMOS
• Package:Tube
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):80 V
• Current - Continuous Drain (Id) @ 25°C:15A (Ta), 105A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):6V, 10V
• Rds On (Max) @ Id, Vgs:4.3mOhm @ 20A, 10V
• Vgs(th) (Max) @ Id:3.3V @ 250µA
• Gate Charge (Qg) (Max) @ Vgs:100 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:5154 pF @ 40 V
• FET Feature:-
• Power Dissipation (Max):1.9W (Ta), 250W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Through Hole
• Supplier Device Package:TO-262
• Package / Case:TO-262-3 Long Leads, I²Pak, TO-262AA
