APT80GA90LD40

Image is for reference, please contact us to get the real picture

Manufacturer Part
APT80GA90LD40
Manufacturer
Roving Networks / Microchip Technology
Description
IGBT 900V 145A 625W TO-264
Category
Discrete Semiconductor Products
Family
Transistors - IGBTs - Single
Series
-
In Stock
0
Datasheets
-

APT80GA90LD40 Specifications

  • Series:POWER MOS 8™
  • Package:Tube
  • Part Status:Active
  • IGBT Type:PT
  • Voltage - Collector Emitter Breakdown (Max):900 V
  • Current - Collector (Ic) (Max):145 A
  • Current - Collector Pulsed (Icm):239 A
  • Vce(on) (Max) @ Vge, Ic:3.1V @ 15V, 47A
  • Power - Max:625 W
  • Switching Energy:1652µJ (on), 1389µJ (off)
  • Input Type:Standard
  • Gate Charge:200 nC
  • Td (on/off) @ 25°C:18ns/149ns
  • Test Condition:600V, 47A, 4.7Ohm, 15V
  • Reverse Recovery Time (trr):25 ns
  • Operating Temperature:-
  • Mounting Type:Through Hole
  • Package / Case:TO-264-3, TO-264AA
  • Supplier Device Package:TO-264
