DMC67D8UFDBQ-13 Specifications

• Series:Automotive, AEC-Q101
• Package:Tape & Reel (TR)
• Part Status:Active
• FET Type:N and P-Channel Complementary
• FET Feature:Standard
• Drain to Source Voltage (Vdss):60V, 20V
• Current - Continuous Drain (Id) @ 25°C:390mA (Ta), 2.9A (Ta)
• Rds On (Max) @ Id, Vgs:4Ohm @ 500mA, 10V, 72mOhm @ 3.5A, 4.5V
• Vgs(th) (Max) @ Id:2.5V @ 250µA, 1.25V @ 250µA
• Gate Charge (Qg) (Max) @ Vgs:0.4pC, 7.3nC @ 4.5V
• Input Capacitance (Ciss) (Max) @ Vds:41pF, 443pF @ 25V, 16V
• Power - Max:580mW (Ta)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Package / Case:6-UDFN Exposed Pad
• Supplier Device Package:U-DFN2020-6 (Type B)
