DMC62D0SVQ-7 Specifications

• Series:Automotive, AEC-Q101
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Discontinued at Digi-Key
• FET Type:N and P-Channel Complementary
• FET Feature:Standard
• Drain to Source Voltage (Vdss):60V, 50V
• Current - Continuous Drain (Id) @ 25°C:571mA (Ta), 304mA (Ta)
• Rds On (Max) @ Id, Vgs:1.7Ohm @ 500mA, 10V, 6Ohm @ 500mA, 10V
• Vgs(th) (Max) @ Id:2.5V @ 250µA
• Gate Charge (Qg) (Max) @ Vgs:0.4nC @ 4.5V, 0.3nC @ 4.5V
• Input Capacitance (Ciss) (Max) @ Vds:30pF @ 25V, 26pF @ 25V
• Power - Max:510mW (Ta)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Package / Case:SOT-563, SOT-666
• Supplier Device Package:SOT-563
