10057596-10020TLF

Image is for reference, please contact us to get the real picture

Manufacturer Part
10057596-10020TLF
Manufacturer
Storage & Server IO (Amphenol ICC)
Description
CONN PCI EXP FEMALE 280POS 0.039
Category
Connectors, Interconnects
Family
Card Edge Connectors - Edgeboard Connectors
Series
-
In Stock
0
Datasheets
-

10057596-10020TLF Specifications

  • Series:-
  • Package:Tray
  • Part Status:Active
  • Card Type:PCI Express™
  • Gender:Female
  • Number of Positions/Bay/Row:11; 38; 91
  • Number of Positions:280
  • Card Thickness:0.062" (1.57mm)
  • Number of Rows:2
  • Pitch:0.039" (1.00mm)
  • Read Out:Dual
  • Features:Board Guide, Locking Ramp
  • Mounting Type:Through Hole
  • Termination:Solder, Staggered
  • Contact Material:Copper Alloy
  • Contact Finish:Gold
  • Contact Finish Thickness:30.0µin (0.76µm)
  • Contact Type:Cantilever
  • Color:Black
  • Flange Feature:-
  • Operating Temperature:-55°C ~ 85°C
