0010181042

Image is for reference, please contact us to get the real picture

Manufacturer Part
0010181042
Manufacturer
Woodhead - Molex
Description
CONN HDR 4POS 0.198 TIN PCB
Category
Connectors, Interconnects
Family
Rectangular Connectors - Headers, Receptacles, Female Sockets
Series
-
In Stock
0
Datasheets
-

0010181042 Specifications

  • Series:3099
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Female Socket
  • Style:Board to Board or Cable
  • Number of Positions:4
  • Number of Positions Loaded:All
  • Pitch - Mating:0.198" (5.03mm)
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Latch Holder
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:50.0µin (1.27µm)
  • Insulation Color:Black
  • Insulation Height:0.421" (10.70mm)
  • Contact Length - Post:0.170" (4.32mm)
  • Operating Temperature:-40°C ~ 105°C
  • Material Flammability Rating:UL94 V-0
  • Contact Finish - Post:Tin
  • Mated Stacking Heights:-
  • Ingress Protection:-
  • Features:Board Guide
  • Current Rating (Amps):5A
  • Voltage Rating:250V
