A3C-16DA-2DSC(71) Specifications

• Series:A3
• Package:Tube
• Part Status:Active
• Connector Type:Receptacle
• Contact Type:Female Socket
• Style:Board to Board or Cable
• Number of Positions:16
• Number of Positions Loaded:All
• Pitch - Mating:0.079" (2.00mm)
• Number of Rows:2
• Row Spacing - Mating:0.079" (2.00mm)
• Mounting Type:Through Hole
• Termination:Solder
• Fastening Type:Push-Pull
• Contact Finish - Mating:Gold
• Contact Finish Thickness - Mating:8.00µin (0.203µm)
• Insulation Color:Black
• Insulation Height:0.165" (4.20mm)
• Contact Length - Post:0.079" (2.00mm)
• Operating Temperature:-55°C ~ 85°C
• Material Flammability Rating:UL94 V-0
• Contact Finish - Post:Tin
• Mated Stacking Heights:5.1mm, 6mm
• Ingress Protection:-
• Features:-
• Current Rating (Amps):1A
• Voltage Rating:200VAC
