BD3932FP-E2 Specifications

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Not For New Designs
• Output Configuration:Positive
• Output Type:Fixed
• Number of Regulators:1
• Voltage - Input (Max):25V
• Voltage - Output (Min/Fixed):8V
• Voltage - Output (Max):-
• Voltage Dropout (Max):1.5V @ 200mA
• Current - Output:500mA
• Current - Quiescent (Iq):30 µA
• Current - Supply (Max):40 µA
• PSRR:55dB (120Hz)
• Control Features:-
• Protection Features:Over Current, Over Temperature, Over Voltage, Reverse Polarity
• Operating Temperature:-40°C ~ 125°C
• Mounting Type:Surface Mount
• Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
• Supplier Device Package:TO-252, (D-Pak)
