74HC4052DB,118 Specifications

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Active
• Switch Circuit:SP4T
• Multiplexer/Demultiplexer Circuit:4:1
• Number of Circuits:2
• On-State Resistance (Max):150Ohm
• Channel-to-Channel Matching (ΔRon):6Ohm
• Voltage - Supply, Single (V+):2V ~ 10V
• Voltage - Supply, Dual (V±):±1.5V ~ 5V
• Switch Time (Ton, Toff) (Max):58ns, 48ns
• -3db Bandwidth:180MHz
• Charge Injection:-
• Channel Capacitance (CS(off), CD(off)):3.5pF
• Current - Leakage (IS(off)) (Max):2µA
• Crosstalk:-60dB @ 1MHz
• Operating Temperature:-40°C ~ 125°C (TA)
• Mounting Type:Surface Mount
• Package / Case:16-SSOP (0.209", 5.30mm Width)
• Supplier Device Package:16-SSOP
