DG612EEN-T1-GE4 Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Switch Circuit:SPST - NO
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:4
• On-State Resistance (Max):115Ohm
• Channel-to-Channel Matching (ΔRon):600mOhm
• Voltage - Supply, Single (V+):3V ~ 12V
• Voltage - Supply, Dual (V±):±3V ~ 5V
• Switch Time (Ton, Toff) (Max):50ns, 35ns
• -3db Bandwidth:1GHz
• Charge Injection:1.4pC
• Channel Capacitance (CS(off), CD(off)):3pF, 3pF
• Current - Leakage (IS(off)) (Max):100pA
• Crosstalk:-74dB @ 10MHz
• Operating Temperature:-40°C ~ 125°C (TA)
• Mounting Type:Surface Mount
• Package / Case:16-UFQFN
• Supplier Device Package:16-miniQFN (1.8x2.6)
