ADG1612BCPZ-REEL Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Switch Circuit:SPST - NC
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:4
• On-State Resistance (Max):1.1Ohm
• Channel-to-Channel Matching (ΔRon):30mOhm
• Voltage - Supply, Single (V+):3.3V ~ 16V
• Voltage - Supply, Dual (V±):±3.3V ~ 8V
• Switch Time (Ton, Toff) (Max):156ns, 87ns
• -3db Bandwidth:38MHz
• Charge Injection:170pC
• Channel Capacitance (CS(off), CD(off)):60pF, 60pF
• Current - Leakage (IS(off)) (Max):300pA
• Crosstalk:-110dB @ 1MHz
• Operating Temperature:-40°C ~ 125°C (TA)
• Mounting Type:Surface Mount
• Package / Case:16-VQFN Exposed Pad, CSP
• Supplier Device Package:16-LFCSP-VQ (4x4)
