FSA1257AL8X Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Switch Circuit:SPST - NC
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:2
• On-State Resistance (Max):1.15Ohm
• Channel-to-Channel Matching (ΔRon):60mOhm
• Voltage - Supply, Single (V+):2.7V ~ 5.5V
• Voltage - Supply, Dual (V±):-
• Switch Time (Ton, Toff) (Max):35ns, 15ns
• -3db Bandwidth:300MHz
• Charge Injection:20pC
• Channel Capacitance (CS(off), CD(off)):11.5pF
• Current - Leakage (IS(off)) (Max):2nA (Typ)
• Crosstalk:-100dB @ 1MHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:8-UFQFN
• Supplier Device Package:8-MicroPak™
