ADG5434BCPZ-REEL7 Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Switch Circuit:SPDT
• Multiplexer/Demultiplexer Circuit:2:1
• Number of Circuits:4
• On-State Resistance (Max):14Ohm
• Channel-to-Channel Matching (ΔRon):300mOhm
• Voltage - Supply, Single (V+):9V ~ 40V
• Voltage - Supply, Dual (V±):±9V ~ 22V
• Switch Time (Ton, Toff) (Max):186ns, 104ns
• -3db Bandwidth:140MHz
• Charge Injection:176pC
• Channel Capacitance (CS(off), CD(off)):15pF, 23pF
• Current - Leakage (IS(off)) (Max):250pA
• Crosstalk:-60dB @ 1MHz
• Operating Temperature:-40°C ~ 125°C (TA)
• Mounting Type:Surface Mount
• Package / Case:20-WFQFN Exposed Pad, CSP
• Supplier Device Package:20-LFCSP-WQ (4x4)
