SN74AUC2G66DCURE4 Specifications

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Active
• Switch Circuit:SPST - NO
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:2
• On-State Resistance (Max):15Ohm
• Channel-to-Channel Matching (ΔRon):1Ohm (Max)
• Voltage - Supply, Single (V+):0.8V ~ 2.7V
• Voltage - Supply, Dual (V±):-
• Switch Time (Ton, Toff) (Max):2.3ns, 2ns
• -3db Bandwidth:50MHz
• Charge Injection:-
• Channel Capacitance (CS(off), CD(off)):2.5pF
• Current - Leakage (IS(off)) (Max):1µA
• Crosstalk:-60dB @ 1MHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:8-VFSOP (0.091", 2.30mm Width)
• Supplier Device Package:8-VSSOP
