ADG507AKRUZ-REEL Specifications

• Series:LC²MOS
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Switch Circuit:-
• Multiplexer/Demultiplexer Circuit:8:1
• Number of Circuits:1
• On-State Resistance (Max):300Ohm
• Channel-to-Channel Matching (ΔRon):15Ohm
• Voltage - Supply, Single (V+):10.8V ~ 16.5V, ±10.8V ~ 16.5V
• Voltage - Supply, Dual (V±):10.8V ~ 16.5V, ±10.8V ~ 16.5V
• Switch Time (Ton, Toff) (Max):300ns, 300ns
• -3db Bandwidth:-
• Charge Injection:4pC
• Channel Capacitance (CS(off), CD(off)):5pF, 22pF
• Current - Leakage (IS(off)) (Max):1nA
• Crosstalk:-
• Operating Temperature:-40°C ~ 85°C
• Mounting Type:Surface Mount
• Package / Case:-
• Supplier Device Package:28-TSSOP
