TS3A44159RGTR Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Switch Circuit:SPDT
• Multiplexer/Demultiplexer Circuit:2:1
• Number of Circuits:4
• On-State Resistance (Max):450mOhm
• Channel-to-Channel Matching (ΔRon):50mOhm
• Voltage - Supply, Single (V+):1.65V ~ 4.3V
• Voltage - Supply, Dual (V±):-
• Switch Time (Ton, Toff) (Max):23ns, 32ns
• -3db Bandwidth:35MHz
• Charge Injection:139pC
• Channel Capacitance (CS(off), CD(off)):50pF
• Current - Leakage (IS(off)) (Max):20nA
• Crosstalk:-73dB @ 100kHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:16-VFQFN Exposed Pad
• Supplier Device Package:16-QFN (3x3)
