TS5A3154YZPR Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Switch Circuit:SPDT
• Multiplexer/Demultiplexer Circuit:2:1
• Number of Circuits:1
• On-State Resistance (Max):900mOhm
• Channel-to-Channel Matching (ΔRon):50mOhm
• Voltage - Supply, Single (V+):1.65V ~ 5.5V
• Voltage - Supply, Dual (V±):-
• Switch Time (Ton, Toff) (Max):16ns, 15ns
• -3db Bandwidth:100MHz
• Charge Injection:12pC
• Channel Capacitance (CS(off), CD(off)):19pF, 36pF
• Current - Leakage (IS(off)) (Max):20nA
• Crosstalk:-64dB @ 1MHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:8-XFBGA, DSBGA
• Supplier Device Package:8-DSBGA, 8-WCSP (1.9x0.9)
