IDAS.C.001 Specifications

• Series:-
• Package:Box
• Part Status:Active
• RF Family/Standard:Cellular, General ISM
• Frequency Group:Wide Band
• Frequency (Center/Band):727.5MHz, 892MHz, 1.795GHz, 1.92GHz, 1.94GHz, 2.595GHz, 3.6GHz
• Frequency Range:699MHz ~ 756MHz, 824MHz ~ 960MHz, 1.71GHz ~ 1.88GHz, 1.85GHz ~ 1.99GHz, 2.5GHz ~ 2.17GHz, 3.4GHz ~ 2.69GHz 3.8GHz
• Antenna Type:Dome
• Number of Bands:7
• VSWR:-
• Return Loss:-25dB, -18dB, -16dB, -15dB, -13dB, -11dB
• Gain:3.4dBi, 2.2dBi, 5.6dBi, 5.1dBi, 5.1dBi, 6.3dBi, 4.7dBi
• Power - Max:50 W
• Features:Cable - 300mm
• Termination:Mini-DIN Female
• Ingress Protection:IP54
• Mounting Type:Panel Mount
• Height (Max):1.496" (38.00mm)
• Applications:DCS, GSM, LTE, PCS, UMTS
