ANT-5GW-SPNF1 Specifications

• Series:-
• Package:Bag
• Part Status:Active
• RF Family/Standard:Cellular
• Frequency Group:Wide Band
• Frequency (Center/Band):657.5MHz, 750.5MHz, 875.5MHz, 1.955GHz, 2.35GHz, 2.593GHz, 3.55GHz, 3.625GHz, 3.95GHz, 4.7GHz
• Frequency Range:617MHz ~ 698MHz, 698MHz ~ 803MHz, 791MHz ~ 960MHz, 1.71GHz ~ 2.2GHz, 2.3GHz ~ 2.4GHz, 2.496GHz ~ 2.69GHz, 3.3GHz ~ 3.8GHz, 3.55GHz ~ 3.7GHz, 3.7GHz ~ 4.2GHz, 4.4GHz ~ 5GHz
• Antenna Type:Module
• Number of Bands:10
• VSWR:1.6, 1.7, 1.8, 3, 3.6, 4.1, 7
• Return Loss:-
• Gain:1.3dBi, 3.3dBi, 3.3dBi, 5.1dBi, 4.5dBi, 5.1dBi, 6.5dBi, 6.5dBi, 6.8dBi, 8.4dBi
• Power - Max:10 W
• Features:-
• Termination:N Type Female
• Ingress Protection:IP67
• Mounting Type:Panel Mount
• Height (Max):2.787" (70.80mm)
• Applications:2G, 3G, 4G, 5G, LTE
