TIL113S1(TB) Specifications

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Active
• Number of Channels:1
• Voltage - Isolation:5000Vrms
• Current Transfer Ratio (Min):300% @ 10mA
• Current Transfer Ratio (Max):-
• Turn On / Turn Off Time (Typ):5µs, 100µs (Max)
• Rise / Fall Time (Typ):-
• Input Type:DC
• Output Type:Darlington with Base
• Voltage - Output (Max):55V
• Current - Output / Channel:-
• Voltage - Forward (Vf) (Typ):1.2V
• Current - DC Forward (If) (Max):60 mA
• Vce Saturation (Max):1.2V
• Operating Temperature:-55°C ~ 100°C
• Mounting Type:Surface Mount
• Package / Case:6-SMD, Gull Wing
• Supplier Device Package:6-SMD
