LE ATB S2W-JW-1+LBMB-24+G Specifications

• Series:OSRAM OSTAR
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Color:Amber, Green, Blue
• Wavelength:619nm Amber, 524nm Green, 464nm Blue
• Current - Test:700mA Amber, 700mA Green, 700mA Blue
• Voltage - Forward (Vf) (Typ):2.5V Amber, 3.6V Green, 3.6V Blue
• Lumens/Watt @ Current - Test:33 lm/W Amber, 83 lm/W Green, 13 lm/W Blue
• Current - Max:1A Amber, 1A Green, 1A Blue
• Luminous Flux @ Current/Temperature:58lm Amber, 210lm Green, 32lm Blue
• Temperature - Test:25°C
• Viewing Angle:120°
• Mounting Type:Surface Mount
• Package / Case:8-SMD Module
• Supplier Device Package:SMD
• Size / Dimension:0.184" L x 0.228" W (4.68mm x 5.80mm)
• Height - Seated (Max):0.048" (1.23mm)
