MENB1020A0903B01 Specifications

• Series:MENB1020 (20W)
• Package:Box
• Part Status:Obsolete
• Region Utilized:North America
• Form:Wall Mount (Class II)
• Input Type:Fixed Blade, Multi-Blade (Sold Separately)
• Voltage - Input:100 ~ 240 VAC
• Voltage - Output:9V
• Current - Output (Max):2A
• Power (Watts):18 W
• No Load Power Consumption:300mW (Max)
• Polarization:Positive Center
• Applications:Medical
• Efficiency:Level V
• Operating Temperature:0°C ~ 40°C
• Output Connector:Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm
• Cord Length:59" (1.50m)
• Input Connector:NEMA 1-15P, Multi-Blade (Sold Separately)
• Size / Dimension:3.31" L x 1.85" W x 1.50" H (84.0mm x 47.0mm x 38.0mm)
• Approval Agency:CB, CE, UL
• Standard Number:-
