PSM04A-050(STD) Specifications

• Series:PSM04A (4W)
• Package:Box
• Part Status:Obsolete
• Region Utilized:North America
• Form:Wall Mount (Class II)
• Input Type:Fixed Blade
• Voltage - Input:90 ~ 264 VAC
• Voltage - Output:5V
• Current - Output (Max):750mA
• Power (Watts):3.8 W
• No Load Power Consumption:500mW (Max)
• Polarization:Positive Center
• Applications:ITE (Commercial)
• Efficiency:Level IV
• Operating Temperature:0°C ~ 45°C
• Output Connector:Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 9.5mm
• Cord Length:70.9" (1.80m)
• Input Connector:NEMA 1-15P
• Size / Dimension:2.73" L x 1.89" W x 0.98" H (69.4mm x 48.0mm x 25.0mm)
• Approval Agency:cULus
• Standard Number:-
