MAP5KE8.5AE3

Image is for reference, please contact us to get the real picture

Manufacturer Part
MAP5KE8.5AE3
Manufacturer
Microsemi
Description
TVS DIODE 8.5V 14.4V DO204AL
Category
Circuit Protection Devices
Family
TVS - Diodes
Series
-
In Stock
0
Datasheets
-

MAP5KE8.5AE3 Specifications

  • Series:Military, MIL-PRF-19500
  • Package:Bulk
  • Part Status:Obsolete
  • Type:Zener
  • Unidirectional Channels:1
  • Bidirectional Channels:-
  • Voltage - Reverse Standoff (Typ):8.5V
  • Voltage - Breakdown (Min):9.44V
  • Voltage - Clamping (Max) @ Ipp:14.4V
  • Current - Peak Pulse (10/1000µs):34.7A
  • Power - Peak Pulse:500W
  • Power Line Protection:No
  • Applications:General Purpose
  • Capacitance @ Frequency:-
  • Operating Temperature:-65°C ~ 150°C (TJ)
  • Mounting Type:Through Hole
  • Package / Case:DO-204AL, DO-41, Axial
  • Supplier Device Package:DO-204AL (DO-41)
