D3002

Image is for reference, please contact us to get the real picture

Manufacturer Part
D3002
Manufacturer
TE Connectivity Potter & Brumfield Relays
Description
RELAY TELECOM DPDT 2A 12VDC
Category
Relays
Family
Signal Relays, Up to 2 Amps
Series
-
In Stock
0
Datasheets
-

D3002 Specifications

  • Series:FP2, AXICOM
  • Package:Tube
  • Part Status:Obsolete
  • Mounting Type:Through Hole
  • Coil Voltage:12VDC
  • Contact Form:DPDT (2 Form C)
  • Contact Rating (Current):2 A
  • Switching Voltage:250VAC, 220VDC - Max
  • Coil Current:11.7 mA
  • Coil Type:Non Latching
  • Features:-
  • Termination Style:PC Pin
  • Seal Rating:-
  • Coil Insulation:-
  • Must Operate Voltage:8.4 VDC
  • Must Release Voltage:1.2 VDC
  • Operate Time:4 ms
  • Release Time:3 ms
  • Operating Temperature:-40°C ~ 85°C
  • Contact Material:Palladium (Pd), Ruthenium (Ru), Gold (Au)
  • Relay Type:Telecom
