8B3021-Z

Image is for reference, please contact us to get the real picture

Manufacturer Part
8B3021-Z
Manufacturer
Nidec Copal Electronics
Description
SWITCH TOGGLE 3PDT 6A 125V
Category
Switches
Family
Toggle Switches
Series
-
In Stock
0
Datasheets
-

8B3021-Z Specifications

  • Series:8B
  • Package:Bulk
  • Part Status:Obsolete
  • Mounting Type:Panel Mount
  • Circuit:3PDT
  • Switch Function:On-Off-On
  • Current Rating (Amps):6A (AC), 4A (DC)
  • Voltage Rating - AC:125 V
  • Voltage Rating - DC:30 V
  • Actuator Type:Standard Round
  • Actuator Length:11.50mm
  • Illumination:Non-Illuminated
  • Illumination Type, Color:-
  • Illumination Voltage (Nominal):-
  • Termination Style:Solder Lug
  • Panel Cutout Dimensions:Circular - 12.50mm Dia
  • Bushing Thread:15/32-32
  • Ingress Protection:-
  • Features:Sealed - Flux Protection
  • Operating Temperature:-20°C ~ 85°C
