NP74N04YUG-E1-AY Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):40 V
• Current - Continuous Drain (Id) @ 25°C:75A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:5.5mOhm @ 37.5A, 10V
• Vgs(th) (Max) @ Id:4V @ 250µA
• Gate Charge (Qg) (Max) @ Vgs:96 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:5430 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):1W (Ta), 120W (Tc)
• Operating Temperature:175°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:8-HSON
• Package / Case:8-SMD, Flat Lead Exposed Pad
