2N7002K,215 Specifications

• Series:TrenchMOS™
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):60 V
• Current - Continuous Drain (Id) @ 25°C:340mA (Ta)
• Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
• Rds On (Max) @ Id, Vgs:3.9Ohm @ 500mA, 10V
• Vgs(th) (Max) @ Id:2V @ 1mA
• Gate Charge (Qg) (Max) @ Vgs:-
• Vgs (Max):±15V
• Input Capacitance (Ciss) (Max) @ Vds:40 pF @ 10 V
• FET Feature:-
• Power Dissipation (Max):830mW (Ta)
• Operating Temperature:-65°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:TO-236AB (SOT23)
• Package / Case:TO-236-3, SC-59, SOT-23-3
