STGF10NC60SD

Image is for reference, please contact us to get the real picture

Manufacturer Part
STGF10NC60SD
Manufacturer
STMicroelectronics
Description
IGBT 600V 10A 25W TP220FP
Category
Discrete Semiconductor Products
Family
Transistors - IGBTs - Single
Series
-
In Stock
0
Datasheets
-

STGF10NC60SD Specifications

  • Series:PowerMESH™
  • Package:Tube
  • Part Status:Obsolete
  • IGBT Type:-
  • Voltage - Collector Emitter Breakdown (Max):600 V
  • Current - Collector (Ic) (Max):10 A
  • Current - Collector Pulsed (Icm):25 A
  • Vce(on) (Max) @ Vge, Ic:1.65V @ 15V, 5A
  • Power - Max:25 W
  • Switching Energy:60µJ (on), 340µJ (off)
  • Input Type:Standard
  • Gate Charge:18 nC
  • Td (on/off) @ 25°C:19ns/160ns
  • Test Condition:390V, 5A, 10Ohm, 15V
  • Reverse Recovery Time (trr):22 ns
  • Operating Temperature:-55°C ~ 150°C (TJ)
  • Mounting Type:Through Hole
  • Package / Case:TO-220-3 Full Pack
  • Supplier Device Package:TO-220FP
