SMS6RE4S6

Image is for reference, please contact us to get the real picture

Manufacturer Part
SMS6RE4S6
Manufacturer
Souriau-Sunbank by Eaton
Description
CONN HEADER VERT 6POS 5.08MM
Category
Connectors, Interconnects
Family
Rectangular Connectors - Headers, Male Pins
Series
-
In Stock
0
Datasheets
-

SMS6RE4S6 Specifications

  • Series:SMS
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.200" (5.08mm)
  • Number of Positions:6
  • Number of Rows:2
  • Row Spacing - Mating:0.200" (5.08mm)
  • Number of Positions Loaded:All
  • Style:Board to Cable/Wire
  • Shrouding:Unshrouded
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Locking Ramp
  • Contact Length - Mating:0.280" (7.11mm)
  • Contact Length - Post:0.173" (4.40mm)
  • Overall Contact Length:0.972" (24.70mm)
  • Insulation Height:0.520" (13.20mm)
  • Contact Shape:Circular
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:16.0µin (0.41µm)
  • Contact Finish - Post:Tin
  • Contact Material:Copper Alloy
  • Insulation Material:Polyester, Glass Filled
  • Features:Mounting Flange
  • Operating Temperature:-55°C ~ 125°C
  • Ingress Protection:IP40
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):5A
  • Voltage Rating:-
