3-822516-3

Image is for reference, please contact us to get the real picture

Manufacturer Part
3-822516-3
Manufacturer
TE Connectivity AMP Connectors
Description
CONN SOCKET PLCC 20POS TIN
Category
Connectors, Interconnects
Family
Sockets for ICs, Transistors
Series
-
In Stock
0
Datasheets
-

3-822516-3 Specifications

  • Series:-
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Obsolete
  • Type:PLCC
  • Number of Positions or Pins (Grid):20 (4 x 5)
  • Pitch - Mating:0.050" (1.27mm)
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:100.0µin (2.54µm)
  • Contact Material - Mating:Phosphor Bronze
  • Mounting Type:Surface Mount
  • Features:Closed Frame
  • Termination:Solder
  • Pitch - Post:0.050" (1.27mm)
  • Contact Finish - Post:Tin
  • Contact Finish Thickness - Post:100.0µin (2.54µm)
  • Contact Material - Post:Phosphor Bronze
  • Housing Material:Thermoplastic
  • Operating Temperature:-
