ADG836YCPZ-REEL Specifications

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Switch Circuit:SPDT
• Multiplexer/Demultiplexer Circuit:2:1
• Number of Circuits:2
• On-State Resistance (Max):650mOhm
• Channel-to-Channel Matching (ΔRon):40mOhm
• Voltage - Supply, Single (V+):1.65V ~ 3.6V
• Voltage - Supply, Dual (V±):-
• Switch Time (Ton, Toff) (Max):26ns, 7ns
• -3db Bandwidth:57MHz
• Charge Injection:40pC
• Channel Capacitance (CS(off), CD(off)):25pF
• Current - Leakage (IS(off)) (Max):200pA (Typ)
• Crosstalk:-90dB @ 100kHz
• Operating Temperature:-40°C ~ 125°C (TA)
• Mounting Type:Surface Mount
• Package / Case:12-VFQFN Exposed Pad, CSP
• Supplier Device Package:12-LFCSP-VQ (3x3)
