ADG407BP-REEL Specifications

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Switch Circuit:-
• Multiplexer/Demultiplexer Circuit:8:1
• Number of Circuits:2
• On-State Resistance (Max):80Ohm
• Channel-to-Channel Matching (ΔRon):4Ohm
• Voltage - Supply, Single (V+):12V
• Voltage - Supply, Dual (V±):±15V
• Switch Time (Ton, Toff) (Max):160ns, 150ns
• -3db Bandwidth:-
• Charge Injection:8pC
• Channel Capacitance (CS(off), CD(off)):5pF, 25pF
• Current - Leakage (IS(off)) (Max):500pA
• Crosstalk:-85dB @ 100kHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:28-LCC (J-Lead)
• Supplier Device Package:28-PLCC (11.51x11.51)
