DG9421DV-T1-E3 Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Switch Circuit:SPST - NC
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:1
• On-State Resistance (Max):3Ohm
• Channel-to-Channel Matching (ΔRon):-
• Voltage - Supply, Single (V+):2.7V ~ 12V
• Voltage - Supply, Dual (V±):±2.7V ~ 6V
• Switch Time (Ton, Toff) (Max):45ns, 47ns
• -3db Bandwidth:-
• Charge Injection:43pC
• Channel Capacitance (CS(off), CD(off)):31pF, 30pF
• Current - Leakage (IS(off)) (Max):1nA
• Crosstalk:-
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:SOT-23-6 Thin, TSOT-23-6
• Supplier Device Package:6-TSOP
