MC74VHC4066DTR2 Specifications

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Switch Circuit:SPST - NO
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:4
• On-State Resistance (Max):70Ohm
• Channel-to-Channel Matching (ΔRon):15Ohm
• Voltage - Supply, Single (V+):2V ~ 12V
• Voltage - Supply, Dual (V±):-
• Switch Time (Ton, Toff) (Max):-
• -3db Bandwidth:160MHz
• Charge Injection:-
• Channel Capacitance (CS(off), CD(off)):10pF
• Current - Leakage (IS(off)) (Max):100nA
• Crosstalk:-80dB @ 1MHz
• Operating Temperature:-55°C ~ 125°C (TA)
• Mounting Type:Surface Mount
• Package / Case:14-TSSOP (0.173", 4.40mm Width)
• Supplier Device Package:14-TSSOP
