ISL43L122IRZ Specifications

• Series:-
• Package:Tube
• Part Status:Obsolete
• Switch Circuit:SPST - NO/NC
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:2
• On-State Resistance (Max):250mOhm
• Channel-to-Channel Matching (ΔRon):5mOhm
• Voltage - Supply, Single (V+):1.65V ~ 3.6V
• Voltage - Supply, Dual (V±):-
• Switch Time (Ton, Toff) (Max):25ns, 25ns
• -3db Bandwidth:-
• Charge Injection:-125pC
• Channel Capacitance (CS(off), CD(off)):182pF, 182pF
• Current - Leakage (IS(off)) (Max):3nA
• Crosstalk:-94dB @ 100kHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:8-WDFN Exposed Pad
• Supplier Device Package:8-TDFN (3x3)
