ISL43231IR-T Specifications

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Switch Circuit:SPDT
• Multiplexer/Demultiplexer Circuit:2:1
• Number of Circuits:3
• On-State Resistance (Max):50Ohm
• Channel-to-Channel Matching (ΔRon):1.3Ohm
• Voltage - Supply, Single (V+):2.7V ~ 12V
• Voltage - Supply, Dual (V±):±2V ~ 6V
• Switch Time (Ton, Toff) (Max):35ns, 22ns (Typ)
• -3db Bandwidth:-
• Charge Injection:0.3pC
• Channel Capacitance (CS(off), CD(off)):3pF, 9pF
• Current - Leakage (IS(off)) (Max):2pA (Typ)
• Crosstalk:-110dB @ 100kHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:20-VFQFN Exposed Pad
• Supplier Device Package:20-QFN-EP (4x4)
