DG2733DN-T1-E4 Specifications

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Switch Circuit:SPDT
• Multiplexer/Demultiplexer Circuit:2:1
• Number of Circuits:2
• On-State Resistance (Max):450mOhm
• Channel-to-Channel Matching (ΔRon):30mOhm
• Voltage - Supply, Single (V+):1.65V ~ 4.3V
• Voltage - Supply, Dual (V±):-
• Switch Time (Ton, Toff) (Max):110ns, 30ns
• -3db Bandwidth:-
• Charge Injection:9pC
• Channel Capacitance (CS(off), CD(off)):104pF
• Current - Leakage (IS(off)) (Max):1nA
• Crosstalk:-75dB @ 100kHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:10-VFDFN Exposed Pad
• Supplier Device Package:10-DFN (3x3)
