TLP2719(LF4,E Specifications

• Series:-
• Package:Tube
• Part Status:Active
• Number of Channels:1
• Voltage - Isolation:5000Vrms
• Current Transfer Ratio (Min):20% @ 16mA
• Current Transfer Ratio (Max):55% @ 16mA
• Turn On / Turn Off Time (Typ):-
• Rise / Fall Time (Typ):-
• Input Type:DC
• Output Type:Transistor with Base
• Voltage - Output (Max):20V
• Current - Output / Channel:8mA
• Voltage - Forward (Vf) (Typ):1.6V
• Current - DC Forward (If) (Max):25 mA
• Vce Saturation (Max):-
• Operating Temperature:-40°C ~ 100°C
• Mounting Type:Surface Mount
• Package / Case:6-SOIC (0.295", 7.50mm Width)
• Supplier Device Package:6-SO
