PC733HJ0000F Specifications

• Series:-
• Package:Tube
• Part Status:Obsolete
• Number of Channels:1
• Voltage - Isolation:5000Vrms
• Current Transfer Ratio (Min):20% @ 100mA
• Current Transfer Ratio (Max):80% @ 100mA
• Turn On / Turn Off Time (Typ):-
• Rise / Fall Time (Typ):4µs, 3µs
• Input Type:AC, DC
• Output Type:Transistor with Base
• Voltage - Output (Max):35V
• Current - Output / Channel:80mA
• Voltage - Forward (Vf) (Typ):1.4V
• Current - DC Forward (If) (Max):150 mA
• Vce Saturation (Max):200mV
• Operating Temperature:-25°C ~ 100°C
• Mounting Type:Through Hole
• Package / Case:6-DIP (0.300", 7.62mm), 5 Leads
• Supplier Device Package:6-DIP
