STMicroelectronics’ model STM32F071VBT6 (click to buy now) is an MCU microcontroller that contains a high-performance Arm® Cortex®-M0 32-bit RISC core operating at up to 48MHz and high-speed embedded memory (up to 128KB of Flash and 16KB of SRAM) , as well as a wide range of enhanced peripherals and I/O.
STM32F071VBT6 provides standard communication interfaces (two I2C, two SPI/one I2S, one HDMI CEC and four USART), a 12-bit ADC, a 12-bit DAC with two channels, seven 16-bit timers, a 32 bit timer and an advanced control PWM timer.
Functional features of STM32F071VBT6
1. High performance: STM32F071VBT6 uses the ARM Cortex-M0 core, which has high performance and high clock frequency, enabling fast data processing and fast response time.
2. Rich peripherals: STM32F071VBT6 integrates a rich set of peripherals, including multiple universal timers (TIMs), universal asynchronous receiver-transmitter (UART), serial peripheral interface (SPI), I2C interface, and analog-to-digital converters (ADC), digital to analog converter (DAC), etc. to meet various application needs.
3. Low-power design: STM32F071VBT6 adopts advanced low-power design technology to achieve low-power operation and standby mode, helping to extend battery life and reduce energy consumption.
4. Rich storage capacity: STM32F071VBT6 has large flash memory and SRAM capacity, which can support complex applications and algorithms while providing sufficient storage space for data storage and caching.
5. Rich communication interfaces: STM32F071VBT6 supports a variety of communication interfaces, such as SPI, I2C, UART, etc., which can realize high-speed data exchange and communication with external devices.
6. Rich development tool support: As a product of STMicroelectronics, STM32F071VBT6 has comprehensive development tool support, including ST-LINK debugger/programmer, development board, software development tools, etc., which helps developers quickly start development and debugging work.
Application fields of STM32F071VBT6
STM32F071VBT6 is a microcontroller based on the ARM Cortex-M0 core and is suitable for a variety of application fields. Its main application fields are as follows:
1. Industrial control: STM32F071VBT6 has rich peripherals, such as timers and communication interfaces, and is suitable for various industrial control applications, such as PLC (programmable logic controller), sensor interfaces, motion control, etc.
2. Home appliances and consumer electronics: STM32F071VBT6 is suitable for use in various home appliances and consumer electronics, such as smart home equipment, power tool controllers, audio equipment, etc.
3. Medical equipment: In the field of medical equipment, STM32F071VBT6 can be used in medical monitoring equipment, portable medical equipment, medical imaging equipment, etc.
4. Communication equipment: STM32F071VBT6 supports a variety of communication interfaces, including SPI, I2C, USART, etc., and is suitable for the field of communication equipment, such as modular communication equipment, Internet of Things terminal equipment, etc.
Parameters of STM32F071VBT6
Brand: STMicroelectronics
Product Category: 32-bit MCU
Package: 100-LQFP(14x14)
Packaging: Pallet
Product application: consumer grade
Core processor: ARMCortex-M0
Kernel specification: 32-bit
Speed: 48MHz
Connectivity: HDMI-CEC, I2C, IrDA, LINbus, SPI, UART/USART
Peripherals: DMA, I2S, POR, PWM, WDT
Number of I/Os: 87
Program storage capacity: 128KB (128Kx8)
Program memory type: Flash
EEPROM capacity:-
RAM size: 16Kx8
Voltage-power supply (Vcc/Vdd): 1.65V~3.6V
Data converter: A/D19x12b; D/A2x12b
Oscillator type: Internal
Working temperature: -40℃~85℃(TA)
Installation type: surface mount type
Pin diagram of STM32F071VBT6
