7760056069

Image is for reference, please contact us to get the real picture

Manufacturer Part
7760056069
Manufacturer
Weidmuller
Description
RELAY GEN PURPOSE DPDT 10A 24V
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
38820
Datasheets
-

7760056069 Specifications

  • Series:DRM
  • Package:Bulk
  • Part Status:Active
  • Mounting Type:Socketable
  • Coil Voltage:24VDC
  • Contact Form:DPDT (2 Form C)
  • Contact Rating (Current):10 A
  • Switching Voltage:250VAC - Max
  • Coil Current:36.9 mA
  • Coil Type:Non Latching
  • Features:Lighted Indicator, Test Button
  • Termination Style:Plug In
  • Seal Rating:-
  • Coil Insulation:-
  • Must Operate Voltage:18 VDC
  • Must Release Voltage:2.4 VDC
  • Operate Time:20 ms
  • Release Time:20 ms
  • Operating Temperature:-40°C ~ 60°C
  • Contact Material:Silver Alloy
  • Relay Type:General Purpose
