IRL80HS120 Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):80 V
• Current - Continuous Drain (Id) @ 25°C:12.5A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
• Rds On (Max) @ Id, Vgs:32mOhm @ 7.5A, 10V
• Vgs(th) (Max) @ Id:2V @ 10µA
• Gate Charge (Qg) (Max) @ Vgs:7 nC @ 4.5 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:540 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):11.5W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:6-PQFN (2x2)
• Package / Case:6-VDFN Exposed Pad
